| Item Type: | MKR Series Board |
| Model Type | MKR WAN |
| Model No.: | ABX00029 |
| Radio | CMWX1ZZABZ |
| Board Power Supply | (USB/VIN) 5V |
| Secure Element | ATECC508 |
| Supported Battery | rechargeable Li-Ion, or Li-Po, 1024 mAh minimum capacity |
| Operating Voltage (V) | 3.3V |
| Digital I/O Pins | 8 |
| PWM Pins | 13 (0 .. 8, 10, 12, 18 / A3, 19 / A4) |
| UART | 1 |
| SPI | 1 |
| I2C: | 1 |
| Analog Input Pins | 7 (ADC 8/10/12 bit) |
| Analog Output Pins | 1 (DAC 10 bit) |
| External Interrupt: | 8 (0, 1, 4, 5, 6, 7, 8, 16 / A1, 17 / A2) |
| DC Current per I/O Pin (mA) | 7 mA |
| CPU Flash Memory | 256 KB (internal) |
| QSPI Flash Memory | 2MByte (external) |
| SRAM | 32 KB |
| EEPROM | NO |
| Clock Speed | 32.768 kHz (RTC), 48 MHz |
| Additional Specs. | 6, LED_BUILTIN |
| USB | Full-Speed USB Device and embedded Host |
| Antenna Gain | 2dB (bundled pentaband antenna) |
| carrier frequency | 433/868/915 MHz |
| Working region | EU/US (confirmed) other countries check your region’s spectrum availability |
| Length (mm): | 67.64 mm |
| Width (mm): | 25 mm |
| Weight (g): | 32 gr. |
