| Item Type: | NEMA 17 Stepper Motor |
| Shaft Type | D Type |
| Step Angle (Degree) | 1.8 |
| Model No.: | JK42HS48-1684-03F |
| Operating Voltage (VDC) | 4.2 ~ 6.0 |
| Supply Current (A) | 1.5A |
| No. of Leads | 6 |
| Inductance: | 5.5 |
| Detent Torque (kg-cm): | 2.6 |
| Shaft Diameter (mm): | 5 |
| Shaft Length (mm): | 22 |
| Step Angle Accuracy | ±5% |
| Inductance Accuracy | ±20% |
| Resistance Accuracy | ±10% |
| Frame Size (mm) | 42 x 42 |
| Cable Length (cm): | 1m |
| Dimensions (L x W x H) mm | 42 X 42 X 72mm |
| Weight (g): | 363 |
