| Operating Voltage (VDC) | 12 |
| Stroke Length (mm): | 100 |
| Force (N): | 1500 |
| Speed (mm/s): | 7 |
| Operating Temperature (°C) | -20 to +63 |
| Mounting Hole Diameter (mm) | 1/4” (6.4mm) |
| Protection level | IP55 |
| Max. Static Load | 337.2 lbs. (1500 Newtons) |
| Max. Current Draw (A) | ≤2A |
| Motor diameter (mm) | 36 mm |
| Speed at No Load (mm/Sec) | 0.28in/sec (7 mm /sec) |
| Speed at Full Load (mm/Sec) | 0.22in/sec (5.5 mm /sec) |
| Noise Level (dB) | 45 dB |
| Length (mm): | 210 |
| Width (mm): | 74 |
| Height (mm): | 36 |
| Weight (g): | 889 |
