| Motor KV (RPM/V) | 170 |
| Torque Constant KT | 0.072 Nm/A @ 5184 rpm |
| Continuous Current (A): | 35 A (180 s) |
| Max. Power (W) | 1634 W (180 s) |
| Voltage Rating (V): | 44V to 52V (12S LiHV) |
| No. of Stator Poles | 24S (24S28P) |
| No. of Bearings | Triple, 626-2Z |
| Output Shaft Diameter (mm) | ø6 |
| Motor diameter (mm) | ø69.5 |
| Motor Length (mm): | 35.7 |
| Motor Weight (g) | 380 |
| Mounting holes | 90 deg: 4xM4 ↧5 mm ø30 mm, 4xM4 ↧5 mm ø40 mm, 4xM4 ↧6 mm ø50 mm |
| Compatible Prop (inch): | 24 |
